初嚐 OpenTelemetry Go Log Beta

Updated
•6 min read•View as Markdown
初嚐 OpenTelemetry Go Log Beta
雷
雷N
Part of seriesObserverbility

在當初寫書跟在公司應用時，OpenTelemetry Go 其實對於 Log 這類型遙測信號還沒實踐，去年都還在草案討論，今年終於在 OTel Go v1.24.0 提出設計。從它們迭代過程中我們也能看到都是從 API 和 Bridge API 開始著手，接著是 Record 結構（v1.25.0），最後才是 SDK （v1.26.0）的實踐。

當初小弟在書上第五章就層介紹到 OTel log record 的結構︰

今天就能來嘗試看看。在此之前 Go 有出 slog 套件，但我之前都覺得用起來沒 OTel + 自己客製化一點點 zap 來的順手。但直到今日我覺得 OTel log bridge 搭配 slog ，用起來幾乎零門檻！

絕大部分內容都參考自官方網站 Doc/Language APIs & SDKs/Go/Getting Started 的內容。今天的內容我有上傳至 OpenTelemetry 入門指南的 Ch5/rolldice 中。

在 Log instrument 的頁面還有提到 log 直接傳送給 collector 與寫到 stdout和file的比較。這部份有機會再寫一篇介紹。

Logger Provider

Logger Provider 主要是給 OTel Log API 的的一個入口點，提供對 Logger 的建立存取與管理。因此 API 應該會提供方法來設定或註冊以及訪問全域的 LoggerProvider。

Logger 才是真的去發送 Log Record 的實例。

這些都在書上第5章有更全面的說明。

func newLoggerProvider() (*log.LoggerProvider, error) {
    logExporter, err := stdoutlog.New(stdoutlog.WithPrettyPrint())
    if err != nil {
        return nil, err
    }

    loggerProvider := log.NewLoggerProvider(
        log.WithProcessor(log.NewSimpleProcessor(logExporter)),
    )
    return loggerProvider, nil
}

接著就能開始設定 SDK ，shutdownFuncs很重要，如果我們要做 Graceful shutdown，把還queue在logger中的records 都送出去，就要依賴它去調用loggerProvider.Shutdown。

Shutdown 的作用在書上第6章有提。

// setupOTelSDK bootstraps the OpenTelemetry pipeline.
// If it does not return an error, make sure to call shutdown for proper cleanup.
func setupOTelSDK(ctx context.Context) (shutdown func(context.Context) error, err error) {
    var shutdownFuncs []func(context.Context) error

    // shutdown calls cleanup functions registered via shutdownFuncs.
    // The errors from the calls are joined.
    // Each registered cleanup will be invoked once.
    shutdown = func(ctx context.Context) error {
        var err error
        for _, fn := range shutdownFuncs {
            err = errors.Join(err, fn(ctx))
        }
        shutdownFuncs = nil
        return err
    }

    // handleErr calls shutdown for cleanup and makes sure that all errors are returned.
    handleErr := func(inErr error) {
        err = errors.Join(inErr, shutdown(ctx))
    }

    // Set up propagator.
    prop := newPropagator()
    otel.SetTextMapPropagator(prop)

    // Set up trace provider.

    // Set up meter provider.

    // Set up logger provider.
    loggerProvider, err := newLoggerProvider()
    if err != nil {
        handleErr(err)
        return
    }
    shutdownFuncs = append(shutdownFuncs, loggerProvider.Shutdown)
    global.SetLoggerProvider(loggerProvider)

    return
}

業務模組的 Logger

通常每個業務模組都會有一個具名的 Logger。這裡只用 Slog 來示範。OTel Go contrib 有提供了 Slog 的 bridge。

import (
    "go.opentelemetry.io/contrib/bridges/otelslog"
)

const name = "go.opentelemetry.io/otel/example/dice"

var (
    logger  = otelslog.NewLogger(name)
)

// 業務行為
func rolldice(w http.ResponseWriter, r *http.Request) {
    // 從 parent span 產生 current span
    ctx, span := tracer.Start(r.Context(), "roll")
    defer span.End()

    roll := 1 + rand.Intn(6)

    var msg string
    if player := r.PathValue("player"); player != "" {
        msg = fmt.Sprintf("%s is rolling the dice", player)
    } else {
        msg = "Anonymous player is rolling the dice"
    }

    // 呼叫 logger 紀錄 Info 事件
    logger.InfoContext(ctx, msg,
        "result", roll)

    rollValueAttr := attribute.Int("roll.value", roll)
    span.SetAttributes(rollValueAttr)
    rollCnt.Add(ctx, 1, metric.WithAttributes(rollValueAttr))

    resp := strconv.Itoa(roll) + "\n"
    if _, err := io.WriteString(w, resp); err != nil {
        log.Printf("Write failed: %v\n", err)
    }

    // 呼叫 logger 紀錄 Error 事件
    logger.ErrorContext(ctx, errors.New("errrrr").Error(),
        "argName", "1212",
        "argName2", 4444)
}

首次執行

make run

curl -X GET http://localhost:8080/rolldice/Alice

Info Log

從下方 Json資料能看見上面表5-2的欄位幾乎都存在於這資料中。連 Trace 與 Span 還有重要的 Recouce 資訊都自動代入了。這裡的Severity Number 是9。

{
    "Timestamp": "2024-11-17T23:30:14.457791572+08:00",
    "ObservedTimestamp": "2024-11-17T23:30:14.457828932+08:00",
    "Severity": 9,
    "SeverityText": "",
    "Body": {
        "Type": "String",
        "Value": "Alice is rolling the dice"
    },
    "Attributes": [
        {
            "Key": "result",
            "Value": {
                "Type": "Int64",
                "Value": 3
            }
        }
    ],
    "TraceID": "6c554d8e71da75aec261bbd8dcfa9171",
    "SpanID": "e0a4005b7be246ef",
    "TraceFlags": "01",
    "Resource": [
        {
            "Key": "service.name",
            "Value": {
                "Type": "STRING",
                "Value": "unknown_service:rolldice_log_demo"
            }
        },
        {
            "Key": "telemetry.sdk.language",
            "Value": {
                "Type": "STRING",
                "Value": "go"
            }
        },
        {
            "Key": "telemetry.sdk.name",
            "Value": {
                "Type": "STRING",
                "Value": "opentelemetry"
            }
        },
        {
            "Key": "telemetry.sdk.version",
            "Value": {
                "Type": "STRING",
                "Value": "1.32.0"
            }
        }
    ],
    "Scope": {
        "Name": "go.opentelemetry.io/otel/example/dice",
        "Version": "",
        "SchemaURL": "",
        "Attributes": {}
    },
    "DroppedAttributes": 0
}

Error Log

我們自定義的參數也都被自動帶入於Attributes 欄位中且判斷出型別。

這裡的Severity Number 是17。

{
    "Timestamp": "2024-11-17T23:30:14.458313377+08:00",
    "ObservedTimestamp": "2024-11-17T23:30:14.45831527+08:00",
    "Severity": 17,
    "SeverityText": "",
    "Body": {
        "Type": "String",
        "Value": "errrrr"
    },
    "Attributes": [
        {
            "Key": "argName",
            "Value": {
                "Type": "String",
                "Value": "1212"
            }
        },
        {
            "Key": "argName2",
            "Value": {
                "Type": "Int64",
                "Value": 4444
            }
        }
    ],
    "TraceID": "6c554d8e71da75aec261bbd8dcfa9171",
    "SpanID": "e0a4005b7be246ef",
    "TraceFlags": "01",
    "Resource": [
        {
            "Key": "service.name",
            "Value": {
                "Type": "STRING",
                "Value": "unknown_service:rolldice_log_demo"
            }
        },
        {
            "Key": "telemetry.sdk.language",
            "Value": {
                "Type": "STRING",
                "Value": "go"
            }
        },
        {
            "Key": "telemetry.sdk.name",
            "Value": {
                "Type": "STRING",
                "Value": "opentelemetry"
            }
        },
        {
            "Key": "telemetry.sdk.version",
            "Value": {
                "Type": "STRING",
                "Value": "1.32.0"
            }
        }
    ],
    "Scope": {
        "Name": "go.opentelemetry.io/otel/example/dice",
        "Version": "",
        "SchemaURL": "",
        "Attributes": {}
    },
    "DroppedAttributes": 0
}

SeverityNumber 與 Log級別 的對應

但其實 OTel 還有個 SeverityText ，這部份可以自己團隊定義，或者就按照 Log level 填入也行。

看起來都很完美！只是！

我習慣看 Caller 資訊，是哪隻模組的哪個檔案的那一行產生 Log event 的。

自定義 Logger

package main

import (
    "context"
    "log/slog"
    "runtime"
)

type CustLogger struct {
    base *slog.Logger
}

func NewCustLoggerLogger(base *slog.Logger) *CustLogger {
    return &CustLogger{base: base}
}

func getCallerInfo() (file string, line int, funcName string) {
    pc, file, line, ok := runtime.Caller(2)
    if !ok {
        return "unknown", 0, "unknown"
    }
    funcName = runtime.FuncForPC(pc).Name()
    return file, line, funcName
}

func (l *CustLogger) InfoContext(ctx context.Context, msg string, keysAndValues ...any) {
    file, line, funcName := getCallerInfo()
    extendedKeysAndValues := append(keysAndValues,
        "caller.file", file,
        "caller.line", line,
        "caller.func", funcName,
    )
    l.base.InfoContext(ctx, msg, extendedKeysAndValues...)
}

func (l *CustLogger) ErrorContext(ctx context.Context, err error, keysAndValues ...any) {
    file, line, funcName := getCallerInfo()
    extendedKeysAndValues := append(keysAndValues,
        "caller.file", file,
        "caller.line", line,
        "caller.func", funcName,
    )
    l.base.ErrorContext(ctx, err.Error(), extendedKeysAndValues...)
}

Logger 也改一下

logger = NewCustLoggerLogger(otelslog.NewLogger(name))

再次執行

make run

curl -X GET http://localhost:8080/rolldice/Alice

漂亮！我有 Caller 資訊了。

{
    "Timestamp": "2024-11-17T23:39:49.11538527+08:00",
    "ObservedTimestamp": "2024-11-17T23:39:49.11542815+08:00",
    "Severity": 9,
    "SeverityText": "",
    "Body": {
        "Type": "String",
        "Value": "Alice is rolling the dice"
    },
    "Attributes": [
        {
            "Key": "result",
            "Value": {
                "Type": "Int64",
                "Value": 5
            }
        },
        {
            "Key": "caller.file",
            "Value": {
                "Type": "String",
                "Value": "/home/nathan/Project/OpenTelemetryEntryBeook/ch5/rolldice/rolldice.go"
            }
        },
        {
            "Key": "caller.line",
            "Value": {
                "Type": "Int64",
                "Value": 51
            }
        },
        {
            "Key": "caller.func",
            "Value": {
                "Type": "String",
                "Value": "main.rolldice"
            }
        }
    ],
    "TraceID": "aa3f83b7b738ce028cfb9f00e1c566dd",
    "SpanID": "b3fa02d56626b129",
    "TraceFlags": "01",
    "Resource": [
        {
            "Key": "service.name",
            "Value": {
                "Type": "STRING",
                "Value": "unknown_service:rolldice_log_demo"
            }
        },
        {
            "Key": "telemetry.sdk.language",
            "Value": {
                "Type": "STRING",
                "Value": "go"
            }
        },
        {
            "Key": "telemetry.sdk.name",
            "Value": {
                "Type": "STRING",
                "Value": "opentelemetry"
            }
        },
        {
            "Key": "telemetry.sdk.version",
            "Value": {
                "Type": "STRING",
                "Value": "1.32.0"
            }
        }
    ],
    "Scope": {
        "Name": "go.opentelemetry.io/otel/example/dice",
        "Version": "",
        "SchemaURL": "",
        "Attributes": {}
    },
    "DroppedAttributes": 0
}

{
    "Timestamp": "2024-11-17T23:39:49.115839158+08:00",
    "ObservedTimestamp": "2024-11-17T23:39:49.115841733+08:00",
    "Severity": 17,
    "SeverityText": "",
    "Body": {
        "Type": "String",
        "Value": "errrrr"
    },
    "Attributes": [
        {
            "Key": "argName",
            "Value": {
                "Type": "String",
                "Value": "1212"
            }
        },
        {
            "Key": "argName2",
            "Value": {
                "Type": "Int64",
                "Value": 4444
            }
        },
        {
            "Key": "caller.file",
            "Value": {
                "Type": "String",
                "Value": "/home/nathan/Project/OpenTelemetryEntryBeook/ch5/rolldice/rolldice.go"
            }
        },
        {
            "Key": "caller.line",
            "Value": {
                "Type": "Int64",
                "Value": 64
            }
        },
        {
            "Key": "caller.func",
            "Value": {
                "Type": "String",
                "Value": "main.rolldice"
            }
        }
    ],
    "TraceID": "aa3f83b7b738ce028cfb9f00e1c566dd",
    "SpanID": "b3fa02d56626b129",
    "TraceFlags": "01",
    "Resource": [
        {
            "Key": "service.name",
            "Value": {
                "Type": "STRING",
                "Value": "unknown_service:rolldice_log_demo"
            }
        },
        {
            "Key": "telemetry.sdk.language",
            "Value": {
                "Type": "STRING",
                "Value": "go"
            }
        },
        {
            "Key": "telemetry.sdk.name",
            "Value": {
                "Type": "STRING",
                "Value": "opentelemetry"
            }
        },
        {
            "Key": "telemetry.sdk.version",
            "Value": {
                "Type": "STRING",
                "Value": "1.32.0"
            }
        }
    ],
    "Scope": {
        "Name": "go.opentelemetry.io/otel/example/dice",
        "Version": "",
        "SchemaURL": "",
        "Attributes": {}
    },
    "DroppedAttributes": 0
}

結論

這次 OTel GO 於 log 的開發結果讓應用開發者的我很滿意，幾乎能無腦轉移。只是覺得SeverityText 能幫忙自動設定log level 進去阿 XD。不過這其實自己客製化也不難。

重點是保證是 structured log 以及自動整合了resource context 與 trace context。蠻多框架輸出的其實並不太是 structured log。但目前還是處於 Beta 階段，很可能使用的方式上還會改動。

至於 slog 怎麼能寫入 log 時被多塞這麼多 OTel 資訊呢？那是因為OTel slog bridge , 就新增一個handler 給slog了。這細節能自己在追蹤就好。

// NewLogger returns a new [slog.Logger] backed by a new [Handler]. See
// [NewHandler] for details on how the backing Handler is created.
func NewLogger(name string, options ...Option) *slog.Logger {
    return slog.New(NewHandler(name, options...))
}

func (l *Logger) log(ctx context.Context, level Level, msg string, args ...any) {
    ... ignore
    _ = l.Handler().Handle(ctx, r)
}

有興趣能購買OpenTelemetry 入門指南：建立全面可觀測性架構（iThome鐵人賽系列書） 電子書來閱讀。

程式內容︰OpenTelemetry 入門指南的 Ch5/rolldice

#opentelemetry#go
813 views

Comments (1)

Join the discussion
K
Ken Chen1y ago

otel 後來有增加對 caller 的支援，現在要加入只要用

logger = otelslog.NewLogger(name, otelslog.WithSource(true))

看起來更方便了
